PoEBlox - Compact 360W PoE Switch
BotBlox
$550.00
Below are the available bulk discount rates for each individual item when you purchase a certain amount
- Buy 5 - 9 and get 5% off
- Buy 10 - 19 and get 7.5% off
- Buy 20 - 49 and get 10% off
- Buy 50 or above and get 12.5% off
Finally! An embeddable PoE switch for Drones and Robots!
4 GigaBit Ethernet Ports and up to 90W per port (360W total)
PoEBlox is a daughterboard that adds full active PoE capability to our range. It is designed as a power delivery daughterboard for GigaBlox Nano, which together forms an ultra compact 4 port gigabit ethernet switch with PoE capability up to 90W per port.
PoEBlox is designed to bring the huge benefits in cost, size and weight of PoE to drones and embedded robotics platforms.
PoEBlox achieves this with the use of an active PSE controller, onboard power FETs, and high power rated RJ45 jacks, all while retaining a very compact form factor.
This system can provide data and power to any standard PoE device, drastically simplifying the construction of PoE based embedded systems.
PoE Standards Compatibility
PoEBlox features a fully featured PSE controller that is compatible with all current active PoE standards detailed below.
| PoE Name | IEEE Standard | Maximum power output per port |
| PoE | IEEE 802.3af | 15.4W, 2 pair |
| PoE+ | IEEE 802.3at | 30W, 2 pair |
| PoE++ | IEEE 802.3bt (Type 3) | 60W, 4 pair |
| PoE++ | IEEE 802.3bt (Type 4) | 90W, 4 pair |
PoEBlox complies with the IEEE PoE standards, and therefore only applies power to a port after the PoE negotiation with a connected device is complete.
This means that PoEBlox will not work with non-standard PoE (where voltage is simply injected on the ethernet lines without negotiation). In these cases, a simple PoE injector can be used.
PoE is instead designed for advanced power hungry devices that comply with the active PoE standards.
Configuration
PoEBlox requires no manual setup; simply assemble it with GigaBlox Nano, apply power (between 48-54V), and connect downstream devices. PoEBlox will then begin automatic negotiation with any connected devices to decide how much power to apply to each port.
- google_product_category:
- Electronics > Networking
- condition:
- new
- custom_product:
- false
- mpn:
- BB-POE-B-1
| Input Voltage Range | 5-60V (48-60V required for PoE operation) |
| Power Consumption | 1W (not including PoE devices or GigaBlox Nano) |
| Ports | 4 x 10/100/1GBASE-T |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +125°C |
| Dimensions | 65mm x 50mm x 14.5mm |
| Port connectors | 4 x Molex PicoBlade |
| HS Tariff Code | 8517.62.00.20 |
| US ECCN | 5A991 |
| Product Status and Lifetime | Active, with a 5-Year Minimum Lifetime |
| Revision | Subrevision | Part number | Release Date | Notes |
|---|---|---|---|---|
| A | 1 | BB-POE-A-1 | 01/11/2020 | Initial release (RJ-45 variant) |
| B | 1 | BB-POE-B-1 | 01/01/2024 | Redesign with Molex PicoBlade connectors and overall board reduction to 65mm x 50mm |
| C | 1 | BB-POE-C-1 | 01/08/2024 | Upgraded STM32 microcontroller to run CLI interface for PoE port management |
